Convection oven 64S and 64L - Dibas

DIBAS 64S and 64L

Technical specifications 64S

• Capacity: 4/5 trays 600 x 400 mm
• Tray distance: 100 / 80 mm
• Dimensions (automatic door): 930 x 1010 x 700 mm
• Dimensions (manual door): 930 x 1055 x 700 mm
• Voltage: 400 V 3N/PE
• Frequency: 50 Hz
• Current: 13.9 A
• Power: 9.6 kW
• Weight: 136 / 143 kg (cascade passive)
• Weight: 134 / 141 kg (cascade active)
• Weight: 119 / 126 kg (pipe steaming)
• Steam type: cascade (optional), pipe steaming (standard/optional)
• Water pressure: 150 – 600 kPa

Technical specifications 64L

• Capacity: 8/10 trays 600 x 400 mm
• Tray distance: 100 / 80 mm
• Dimensions (automatic door): 930 x 1010 x 1100 mm
• Dimensions (manual door): 930 x 1055 x 1100 mm
• Voltage: 400 V 3N/PE
• Frequency: 50 Hz
• Current: 27.5 A
• Power: 19 kW
• Weight: 205 / 212 kg (cascade passive)
• Weight: 200 / 207 kg (cascade active)
• Weight: 170 / 177 kg (pipe steaming)
• Steam type: cascade (optional), pipe steaming (standard/optional)
• Water pressure: 150 – 600 kPa
